Brand Name : | Grassland |
Model Number : | 100X3.0X16 |
Certification : | MPA EN 12413 and ISO 9001 |
Price : | US$0.16-0.25 |
Payment Terms : | T/T, L/C, Western Union, MoneyGram |
Supply Ability : | 300 thousand PCS PER day |
Delivery Time : | 30-60 Days |
METAL CUTTING WHEEL 125 X 3 X 22.23MM TYPE 42 GRASSLAND
Engineered with high-grade aluminium oxide + phenolic resin steel, these cutting discs perform much more aggressive cutting in metal and stainless with safety and more efficiency.
This metal cutting wheel is ideal for the smooth cutting required in industrial applications. The 5 inches cutting wheel can cut through any metal effortlessly and is very easy to use. The GRASSLAND metal cutting wheel is designed for best efficiency in heavy-duty condition.
Wheel thicknesses 3.2/3.0 mm for maximum tool life and high lateral stability.Multilevel excellent glass fiber mesh and resin as reinforced bonded material. High cutting efficiency.
Application
Type 42 depressed center cutting wheel, increase side strength and
improve abrasive resistance, which get excellent durability and
sharpness.quickly and effortlessly cutting through All Metal, Steel and
Stainless Steel including rebar, steel pipe, structural &
galvanized steel, sheet metal, structural tubing, black steel
Cutting wheel information: | |||
Product Name | 125 mm cutting wheel | Abrasive | Aluminum oxide and corundum |
Hardness | R Grade | Net Grade | Reinforced fiberglass |
Max working speed | 80 m/s | OEM Service | Acceptable |
R.P.M | 12250 | Package | Kraft Carton and Pallet |
Grit size | 46#,60# | HS Code | 68042210 |
Certificate | MPA EN12413,ISO9001 | Loading Port | Tianjin or else |
Description of goods | Item No | Specification | Unit | PCS/CTN | N.W./G.W.(KGS) | CARTON SIZE(CM) |
Depressed Cutting disc for metal 80m/s | DAC1002516 | T42-100X2.5X16MM | PC | 200 | 8/9 | 22*22*20.2 |
DAC1152522 | T42-115X2.5X22.2MM | PC | 200 | 12/13 | 24.5*24.5*20.2 | |
DAC1252522 | T42-125X2.5X22.2MM | PC | 200 | 14/15 | 26.5*26.5*20.2 | |
DAC1502522 | T42-150X2.5X22.2MM | PC | 150 | 15/16 | 34*26*17 | |
DAC1802522 | T42-180X2.5X22.2MM | PC | 150 | 19.5/20.5 | 40*20*26 | |
DAC2302522 | T42-230X2.5X22.2MM | PC | 50 | 11.5/12.5 | 24*24*20.7 | |
DAC2502522 | T42-250X2.5X22.2MM | PC | 50 | 11.5/12.5 | 25*25*19 | |
Depressed Cutting disc for metal 80m/s | DAC1003216 | T42-100X3.2X16MM | PC | 400 | 21.5/20.5 | 22X22X19.7 |
DAC1153222 | T42-115X3.2X22.2MM | PC | 200 | 14/15 | 24.5*24.5*22.2 | |
DAC1253222 | T42-125X3.2X22.2MM | PC | 200 | 16/17 | 26.5*26.5*22.2 | |
DAC1503222 | T42-150X3.2X22.2MM | PC | 200 | 25/26 | 32*32*22.2 | |
DAC1803222 | T42-180X3.2X22.2MM | PC | 100 | 18/19 | 37.5*19*23.7 | |
DAC2303222 | T42-230X3.2X22.2MM | PC | 50 | 14/15 | 24*24*23.7 | |
DAC2503222 | T42-250X3.2X22.2MM | PC | 50 | 17.5/16.5 | 25*25*21 |
![]() |
