Brand Name : | Grassland |
Model Number : | 115X1.0X22.23 |
Certification : | MPA EN 12413 and ISO 9001 |
Price : | US$0.20-0.26 |
Payment Terms : | T/T, L/C, Western Union, MoneyGram |
Supply Ability : | 300 thousand PCS PER day |
Delivery Time : | 30-60 Days |
JZX T41-115X1.2X22mm 4.5" super Thin 1mm thickness inox Cutting Disk
Products Descriptions:
•Diameter: 115mm (4.5 inch)
•Thickness: 1.mm
•Hole/Bore: 22.23mm
•Vmax: 80 m/s
•Max RPM: 13300
Key Points:
- Can be used to cut all types of steel
- Suits angle grinders with a 22mm chuck
- Thinner disc means a faster & cooler cutting action. An absolute
must for Stainless Steel
- Complies to AS 1788.1-1987 DIN EN 12413
Grassland discs have been developed for precision cutting sheet metal and with strengthened core stability for reduced vibration. This very thin 1.0mm disc enables you to achieve a uniquely clean cut in the shortest possible time while using a minimum of force. Precise to the millimetre, vibration-free cutting, no thermal bluing and no burring precluding the need for subsequent machining.
The INOX disc provides fast, precise cuts in stainless steel with
minimum friction, preventing hot corrosion. The Grassland INOX
cutting disc offers excellent abrasive performance and extra long
working life for stainless steel cutting as well as quick cuts in
other metals.
Field of Application:
They are widely used for cutting stainless steel or non-metal materials and removing rust.Thus,achieving fast,better and economical results.
Cutting wheel information: | |||
Product Name | 4.5” Inox cutting disc | Abrasive | Aluminum oxide SA |
Hardness | R Grade | Net Standard | Reinforced fiberglass |
Max working speed | 80 m/s | OEM Service | Acceptable |
R.P.M | 13300 | Package | Normal Kraft Carton and Pallet |
Grit size | 46#,60# | HS Code | 68042210 |
Certificate | MPA EN12413,ISO9001 | Loading Port | Tianjin or else |
--Big size cutting wheel for inox&stainless steel
Description of goods | Item No | Specification | Unit | PCS/CTN | N.W./G.W.(KGS) | CARTON SIZE(CM) |
Flat cutting disc for inox 80m/s | FSC3003225 | T41-300X3.2X25.4MM | PC | 25 | 13/14 | 30*30*9.5 |
FSC3004025 | T41-300X4.0X25.4MM | PC | 25 | 14/15 | 30*30*11 | |
FSC3503225 | T41-350X3.2X25.4MM | PC | 25 | 17/18 | 35.5*35.5*9.5 | |
FSC3504025 | T41-350X4.0X25.4MM | PC | 20 | 17/18 | 35.5*35.5*9.5 | |
FSC4003225 | T41-400X3.2X25.4MM | PC | 25 | 22/23 | 40*40*9.5 | |
FSC4004025 | T41-400X4.0X25.4MM | PC | 20 | 22/23 | 40*40*9.5 |
---Depressed center rough discs for metal
Description of goods | Item No | Specification | Unit | PCS/CTN | N.W./G.W.(KGS) | CARTON SIZE(CM) |
Depressed Cutting disc for inox 80m/s | DSC1003216 | T42-100X3.2X16MM | PC | 400 | 21/22 | 22X22X37.7 |
DSC1153222 | T42-115X3.2X22.2MM | PC | 200 | 14/15 | 24.5*24.5*22.2 | |
DSC1253222 | T42-125X3.2X22.2MM | PC | 200 | 16/17 | 26.5*26.5*22.2 | |
DSC1503222 | T42-150X3.2X22.2MM | PC | 200 | 25/26 | 32*32*22.2 | |
DSC1803222 | T42-180X3.2X22.2MM | PC | 100 | 18/19 | 37.5*19*23.7 | |
DSC230322 | T42-230X3.2X22.2MM | PC | 50 | 14/15 | 24*24*23.7 | |
DSC2503222 | T42-250X3.2X22.2MM | PC | 50 | 17.5/16.5 | 25*25*21 |
![]() |
